STANDARD FEATURES:
- Configured for LP Gas
- Control - Digital thermostat (allows for cook temperature selection only, 140° to 325°F (60° to 163°C))
- Rack hangers - (5) 3-tier, 3-1/2” (89mm) spacing, hanger assemblies
- Product racks - (15) 12” x 42” (305 x 1067mm) nickel chrome plated• Heat source - 75,000 BTU (22KW) burner with electronic pilot
OPTIONAL FEATURES (PLEASE CONTACT FOR PRICING):
- Programmable digital cook and hold control (140° to 325°F)(60° to 163°C)
- Glass product display doors upgrade
- Stainless steel product rack upgrade, (15) 12” x 42"(305 x 1067mm)(substitution of standard chrome racks)
ACCESSORIES:
- Smoke extractor damper Part# 593004
- Mobile evacuation system (Fan & Curb) Part# 597067
- Product shelf Part# 993002
- Lockable control panel cover Part# 291017
- Drain pan with hose for cleaning Part# 912021
- Mobile rack retainer pins and clips
Trailer Features:
- Black paint
- Torsion axle
- 2" coupler
- Safety chains
- LED lighting
- 7-way RV trailer plug connector
- A-frame coupler mounted jack with interchangeable foot plate and caster
- Mobile rack retainer pins and clips for smoker
- Stainless steel open storage box
- Dual 40lb LP tank assembly (in open stainless steel box)
- 15" chrome spoke wheels and radial tires (with spare)
Gas Specifications
* Natural or LP gas
* 75,000 BTU (22KW) burner
* 1/2" gas inlet (NPT)
* Supply line pressure
Natural - 4.5" W.C. min - 10.0" W.C. max (11.2 - 26.5 mbar)
LP - 11.0" W.C. min - 13.0" W.C. max (27.4 - 32.4 mbar)
Electrical Specifications
* 120 volt AC, 60 hertz, 1-phase, 15 amp wiring w/NEMA 5-15P plug -or-
* 230 volt AC, 50 hertz, 1-phase, 15 amp wiring w/no plug provided
Ventilation Specifications
* The smoker must be vented in accordance with the Owner's Manual and the installation must comply with all relevant local and national codes and in a manner acceptable to the authority having jurisdiction.
Smoker Specifications
* Smoker exterior dimensions - 61 5/8"w x 75"d x 71 1/8"h (1565 x 1905 x 1807mm)
* Smoker weight - 1,204 lbs (546kg)
Approximate Smoker Capacities:
Pork Butts (8-10 lbs)(3.6 - 4.5 kg) each......60 pieces
St. Louis Ribs (2.75 lbs)(1.2kg) each...........60 pieces
Whole Chicken (3-4 lbs)(1.4 - 1.8 kg) each..70 pieces
Beef Brisket (12-15 lbs)(5.4 - 6.8 kg) each..20 pieces
Capacities will vary based on product specifications and loading method.
